Consider the circuit shown in Fig. 5.25a. Determine the Thévenin equivalent of network A, and compute the power delivered to the load resistor R_{L}.

Use Thévenin’s theorem to determine the Thévenin equivalent for that part of the circuit in Fig. 5.25a to the left of R_{L}.

Thévenin’s theorem to ﬁnd the current through the 2Ω resistor in the circuit of Fig.5.28. (Hint: Designate the 2Ω resistor as network B).
